100 mA Fixed X-Ray Machine STARNUKE-FX100 Line Frequency

100 mA Fixed X Ray Machine STARNUKE-FX100 Line Frequency

Presenting Starnuke's Line Frequency 100 mA Fixed X-Ray Machine: this powerful but also reliable machine will ensure excellent image quality for any clinic or medical center looking for dependable and easy-to-operate diagnostic equipment.

The Starnuke 100 mA Fixed Diagnostic X-Ray Machine without HBT Table Line Frequency, made by us, offers the perfect tube head motion that comes with an instinctive user interface. It provides high-quality, high-resolution images for the most demanding needs of diagnostic radiology investigations. Due to these characteristics, it is the ideal machine for every hospital, clinic, and diagnostic center.



Technical Specification

• Model: Starnuke 100 mA Fixed X-Ray Machine
• Radiography: 100 mA at 100 kVp
• Tube Current: F(0-3 mA), 25 mA, 50 mA, 75 mA & 100 mA
• Tube Voltage: 40-100 kVp (15 Steps)
• Timer: 0.02-5 Seconds (24 Steps)
• X-Ray Tube: Indian/Imported stationery anode
• Collimator: Manual light beam diaphragm
- Power Supply: Single Phase 230 + 10 V, 50 Hz
- Rectification: Full wave rectified using silicon rectifiers



Applications

1. Hospitals
    For hospitals requiring an efficient and qualitative imaging system to assure proper diagnosis among the patients.

2. Clinics
Ideal for small to medium clinics where reliability and ease of operation are paramount in patient care.

3. Diagnostic Centers
   It meets the high demand for diagnostic centers in order to provide fine resolution for accurate diagnoses.

4. Radiology Departments
   This will be a good partner in the radiology departments since it improves the work of the workflow and enhances diagnostic capabilities.
