Smart Prima X: High-Performance Portable X-Ray Machine for Veterinary Use
The Smart Prima X portable X-ray machine is designed to meet the demanding needs of modern veterinary practices. With a lightweight and compact design, powerful imaging capabilities, and customizable settings, it provides precise diagnostic solutions for both small and large animals. Whether in an animal hospital, a mobile veterinary clinic, or the field, this X-ray system ensures fast and reliable imaging with ease of use.
Technical Specification
Max. Working Frequency
>/-250kHz
Voltage Range
110/220VAC +/- 10% / 48VDC
Nominal/Max
5.6/6.8kW
kV Range
40~125kV
kV Rising Time
</- 1ms @100kV (10%-90%)
mA Range
5~100mA
mAs Range
0.1~320mAs @110/220VAC
0.1~100mAs @48VDC
Tube Model
KL10-0.6/1.8-125
Nominal Focal Spot Size
0.6/1.8mm
Dimensions
Weight
383240215mm
15kg
Key Features for Veterinary Professionals
1. Lightweight and Easy-to-Carry Design
Weighing just 15 kg and measuring 265mm x 240mm x 210mm, the Smart Prima X is easy to move, making it suitable for mobile vets. Its ergonomic design ensures comfortable handling for long shifts and simplifies on-site diagnostics, even in remote areas.2. High-Precision Imaging with Adjustable Settings
The X-ray system offers 40-125kV power with a 5-100mA range, providing the flexibility needed for accurate imaging of different animal types. This allows veterinarians to capture clear radiographs for soft tissue and bone conditions, ensuring high diagnostic value across species.3. Versatile Exposure Options
The mAs range of 0.1-320mAs ensures that every animal gets the appropriate radiation dose. With exposure times from 1 ms to 4000 ms, the device accommodates both quick and detailed imaging needs, from routine exams to complex diagnostics.4. Multiple Focal Spot Sizes for Clear Imaging
Equipped with dual focal points (0.6mm and 1.8mm), the machine can switch between detailed soft tissue scans and high-resolution bone imaging. This feature makes it easier to manage a variety of cases, from dental assessments to orthopedic issues.5. Built-in Filtration for Safety and Image Quality
The 0.6mm aluminum filter helps remove unnecessary radiation, reducing exposure risks while improving image clarity. This ensures safer diagnostic procedures for both animals and veterinary staff.6. Wireless Operation for Remote Use
The Smart Prima X offers wireless communication, allowing veterinarians to operate the system remotely. This is especially useful for field clinics or mobile services, where collaborating with radiologists from a distance can enhance diagnostic accuracy.7. Long Battery Life for Mobile Diagnostics
With a single charge, the internal battery provides up to 200 X-ray exposures, making the machine dependable during extended shifts or remote operations. This ensures consistent performance, whether working in the clinic or at an off-site location.8. Energy-Efficient Operation for Longevity
The system integrates soft-switching technology, reducing energy loss and preventing excessive heat buildup. This enhances the machine’s durability and ensures efficient operation, even with frequent use.9. Customizable Veterinary Interface
Smart Prima X features a user-configurable APR system designed specifically for animal care. Veterinarians can tailor the settings to match the body part or species, ensuring optimal image quality and reducing unnecessary retakes.10. Dual Power Options for Continuous Operation
The machine can run on both battery and AC power, ensuring seamless use in any setting— from busy clinics to remote farms. This flexibility allows veterinarians to stay prepared for any situation without worrying about power interruptions.Applications in Veterinary Care
1. Animal Clinics
The Smart Prima X delivers clear, high-quality radiographs for pets like cats, dogs, and rabbits. It is ideal for soft tissue, orthopedic, and dental imaging, providing accurate results that improve patient outcomes.2. Mobile Veterinary Services
Its lightweight, portable design makes it perfect for veterinarians traveling between client homes, animal shelters, and farms. Portable imaging ensures faster diagnoses and less stress for animals during treatment.3. Equine and Large Animal Imaging
Designed to handle large animals, the Smart Prima X offers the power and precision required for horses, cattle, and sheep. It provides detailed images for everything from joint issues to fractures, making it essential for both field vets and animal hospitals.4. Emergency Veterinary Clinics
The machine’s reliable battery and remote operation capabilities ensure consistent performance during emergency situations or in areas without access to power. It’s a valuable tool for wildlife rescue missions or disaster response teams.
